AUD-DTE-ECODE · AUD-DTE-LINEIN · AUD-DTE-XLRIN · AUD-DTE-HDMI · AUD-DTE-BT
KanexPro offers five Dante input adapters, each designed to bring a different signal type onto the Dante network. All are PoE powered, 2-channel, and fully compatible with Dante Controller and AES67.
AUD-DTE-ECODE — Analog Line Input Encoder
AUD-DTE-ECODE · PoE powered
Converts balanced or unbalanced stereo analog line-level audio to Dante. Accepts any line-level source: mixer outputs, DSP outputs, consumer/pro stereo sources. 5-level input sensitivity adjustment. Use when the source has standard line-level outputs (RCA, 3.5mm, or balanced terminals).
AUD-DTE-LINEIN — Analog Line Input Adapter
AUD-DTE-LINEIN · PoE or USB-C powered
Compact balanced/unbalanced 2-channel analog line input. Similar function to AUD-DTE-ECODE with a more compact form factor and USB-C power option. Ideal where rack space is limited or PoE is unavailable.
AUD-DTE-XLRIN — XLR Input Adapter
AUD-DTE-XLRIN · PoE powered
Converts professional 3-pin XLR balanced audio to Dante. Purpose-built for microphones, mixing consoles, stage boxes, and professional audio equipment. Choose when the source uses XLR connectors and professional balanced levels.
AUD-DTE-HDMI — HDMI to Dante Encoder
AUD-DTE-HDMI · PoE powered
Extracts embedded audio from any HDMI source and presents it as a 2-channel Dante transmitter — no analog conversion, no signal loss. HDMI video passes through to the display. Eliminates the need for a separate audio de-embedder plus Dante adapter.
AUD-DTE-BT — Bluetooth Input Adapter
AUD-DTE-BT · PoE powered
Streams Bluetooth 5.1 audio from any compatible device into the Dante network. APTX-LL (low latency) and APTX-HD (high resolution). For presenters, musicians, or guests who need to wirelessly contribute audio without a physical connection. Bluetooth input is wireless; Dante output is always wired.
Comparison
| SKU | Input | Gain Adjust | Power |
|---|---|---|---|
| AUD-DTE-ECODE | Balanced/Unbalanced | 5-level | PoE |
| AUD-DTE-LINEIN | Balanced/Unbalanced | 5-level | PoE / USB-C |
| AUD-DTE-XLRIN | XLR professional | Yes | PoE |
| AUD-DTE-HDMI | HDMI embedded audio | N/A | PoE |
| AUD-DTE-BT | Bluetooth 5.1 (APTX) | N/A | PoE |
Setup (All Input Adapters)
- Connect to a PoE-capable managed switch port on the Dante VLAN
- Connect the audio source to the appropriate input
- Open Dante Controller — device appears as a transmitter within seconds
- Subscribe a Dante receiver (output adapter, amp, DSP) to the transmitter channels
- Adjust input gain as needed
